| Material: | Carbon Steel Q345B | Suspension: | Spring Suspension |
|---|---|---|---|
| Axle: | Fuwa Brand 13 Tons | Loading Capacity: | 100 Tons |
| High Light: | Spring Suspension Low Bed Semi Trailer,100T Low Bed Semi Trailer,100T Low Bed Trailer |
||
Material
The main frame is made of 16Mn high-tensile steel, reasonable structure, superior carrying capacity and no permanent deformation; It can be reinforced according to using requirement.
Performance
The axle,tire and other accessories are the well-known products which supplied by the domestic and foreign professional manufacturers.The quality can keep better.
Loading
The continuous improvement of structure makes it much accord with practical loading and unloading requirements. Long with heavier loads.They can carry and transport big rocks, heavy, hard-to-move machinery.The low bed trailer can be custom-built as your requirements. The payload can reach to 200 tons.
Specification
| Feature: | Carry containers, bulk cargo, heavy equipment |
| Dimension(L*W*H): | 16500*3200*2500mm (custom-built) |
| Main frame: | Heavy duty and extra durability design; High tensible low carbon alloy Q345B steel |
| Model: | SS9700TDP |
| No. of axle: | 5 |
| Payload: | 40,000 to 80,000kgs |
| Kingpin: | The world-famous JOST brand bolt-in/welded type 3.5”/2” |
| Landing gear: | JOST brand two-speed manual operation 19” |
| Tire size: | 11R22.5 (Optional) |
| Rim size: | 9.00*22.5 |
| Axle: | L1 Brand /Fuwa Brand |
| Suspension | Fuwa brand with 8pcs of leafs spring |
| Brake system: | Dual line Re-6 emergency relay valve, T30/30 air chamber, 46L air tank |
| Electric system: | One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable |
| Container locks | 12(for 1x20GP,2X20GP,1X40HQ) |
| Painting: | S.A.2.5standard sandblasting; Two coat of anti-corrosion prime; one coat of finish painting |
| Accessory: | One tool box |
Quality guarantee
1. More than 30 years experiences in trailer and truck industrial,exported to more than 30 countries in Africa,Southeast Asia.
2. Two years free warranty terms for the I beam,three to six month free warranty terms for the Axles,suspension etc.
3. Spare parts support services.
4. Able to custom-built design as your requirement,ensure to meet your local road regulation.
